Gasoline generator set RUBRUKS REX-35-360

Артикул: REX-35-360
Gasoline generator set RUBRUKS REX-35-360Gasoline generator set RUBRUKS REX-35-360Gasoline generator set RUBRUKS REX-35-360Gasoline generator set RUBRUKS REX-35-360Gasoline generator set RUBRUKS REX-35-360
Gasoline generator set RUBRUKS REX-35-360
Gasoline generator set RUBRUKS REX-35-360
Gasoline generator set RUBRUKS REX-35-360
Gasoline generator set RUBRUKS REX-35-360
Gasoline generator set RUBRUKS REX-35-360
0 Р
Получить консультацию
Скачать 3D-модель
Производитель:
RUBRUKS
• Nom power output, kW - 35
• Output voltage, V - 200…750
Поделиться:
Motor type RUBRUKS HVM-PM1-55
Traction inverter type RUBRUKS NTPI-600-50
Engine type VAZ 21124
Rated power output, kW 35
Maximum power output, kW 45
Output voltage, V 200…750
Current output max, A 150
Interface CAN
Overall dimensions (LxWxH) 804х456х667
Производитель: RUBRUKS

Gasoline generator set with the ability to operate in Range Extender mode for electric vehicles.

A Range Extender is a device that allows you to charge traction batteries from the internal combustion engine while the vehicle is moving.
The difference from conventional gasoline generator sets is that an AC/DC converter is already installed on board, controlling the current and voltage to charge the battery.
The solution assumes the possibility of modification to suit the configuration of the final product.

Оформить заказ на Gasoline generator set RUBRUKS REX-35-360 вы можете в компании Рубрукс отправив заявку по почте, а также по телефону или в офисе компании .
